Atosa AUF60D4 60-1/4″ Undercounter Freezer with Four Drawers

Description

The Atosa AUF60D4 is a 60-1/4″ undercounter freezer with four drawers and 15.5 cu ft of capacity, the largest model in the Atosa AUF series. It is made for long cook lines and high-volume kitchens that want a full run of frozen storage built into the work surface, from bulk proteins to ice cream and prepared sides. Atosa lists it with standard 1/6 size pans and an electronic controller for simple day-to-day operation.

Key features

• Four drawers, 15.5 cu ft – organized frozen storage that opens right at the work surface.
• Holds -8°F to 1°F – for frozen proteins, fries and desserts.
• Stainless steel exterior and interior – with a reinforced stainless top.
• Electronic temperature controller – easy to set and read.
• R290 refrigerant – an environmentally friendly hydrocarbon refrigerant.
• Magnetic drawer gaskets – seal each drawer tightly to help hold temperature.
• Recessed handles – nothing to snag.
• 1/6 size pans included – included with every unit.
• 2″ heavy-duty swivel plate casters – pre-installed, so the unit rolls out for cleaning.

How the AUF60D4 fits your kitchen

At 15.5 cu ft, it suits busy restaurants, hotel banquet lines and commissary kitchens that would otherwise rely on several smaller units or constant walk-in trips. It measures 60-1/4″ wide by 30″ deep and 32-3/8″ high on the standard casters, and weighs 319 lb net. It plugs into a standard 115 V, 60 Hz, single-phase outlet (NEMA 5-15P, 4.8 A) and Atosa asks for a dedicated, grounded supply. Keep the rear at least 5″ from the wall for airflow, and install it in a space between 50°F and 100°F.

Other sizes in this series

• AUF27D2 – 27-1/2″ wide, two drawers, 6.5 cu ft.
• AUF36D2 – 36-3/8″ wide, two drawers, 9 cu ft.
• AUF48D4 – 48-1/4″ wide, four drawers, 12.2 cu ft.

Why buy from Babak Food Equipment?

• Authorized Atosa dealer – sales, service and installation options, with warranty support coordinated with Atosa.
• 20+ years in business and a 4.9★ Google rating from 380+ reviews.
• Expert advice – our team helps you compare models and check power, gas and ventilation requirements.
• Delivery and installation options across BC – details and costs are discussed when you order.

FAQ

What power does the Atosa AUF60D4 need?
It runs on 115 V, 60 Hz, single phase, rated at 4.8 A, with a NEMA 5-15P plug. Atosa calls for a dedicated, grounded outlet and at least 5″ between the rear and the wall.

How do I clean and maintain the AUF60D4?
Clean the condenser at least monthly with a vacuum or soft brush, never a wire brush, after disconnecting power. Wipe the interior, exterior and drawer gaskets with a soft cloth and neutral detergent. Never hose it down or use abrasives.

Where can I find the AUF60D4 spec sheet?
The official Atosa spec sheet for the AUF60D4 is in the download section below, along with the AUR/AUF manual. Together they cover dimensions, electrical data, caster options and pan configurations.

Is the AUF60D4 the same as the AWF60D4 in the spec table?
Yes. The AUF60D4 is the model named on the Atosa spec sheet and product page. The 60-1/4″ unit has four drawers, 15.5 cu ft and a 4.8 A draw. Our figures follow the official spec sheet, so please quote the model as AUF60D4.

Please request a quote to confirm availability before you buy. Pricing, availability, warranty terms, delivery and installation are all confirmed at the time of purchase.
