Atosa ATCM-36 36″ Infrared Cheesemelter with Range Mount Kit
Exclusive Price :​
Original price was: $1,997.00.$1,375.00Current price is: $1,375.00.
Need Help :
Specs
| Weight | 95 lbs |
|---|---|
| Brand | Atosa |
| Gas Type | Natural gas or propane (LP) |
| Number of Burners | 2 |
| Burner Style | Ceramic infrared burners |
| Model | ATCM-36 |
| Width | 36″ |
| Total BTU | 43,000 BTU/h |
| BTU | 21,500 per burner |
| Control | Independent manual control (dual valves) |
| Valve Types | Standby pilots |
| Exterior Material | Stainless Steel |
| Installation | Range mount (kit included) |
| Gross Weight (lbs) | 119 lbs |
| Certificate | ANSI Z83.11, CSA 1.8, NSF/ANSI 4 |
| Depth | 18″ |
| Height | 17-1/3″ |
| Gas Pressure | NG 5″ w.c. / LP 10″ w.c. |
| Intake Tube Thread | 3/4″ |
| Broiler Rack | Removable, with crumb catcher |
| Optional Wall Mount Kit | Part # 21208001048 |
Description
The Atosa ATCM-36 is a 36″ infrared cheesemelter that finishes gratin dishes, melts cheese on burgers and nachos, and toasts and browns the top of plated food in seconds. Two ceramic infrared burners on separate valves let a cook run half the broiler or all of it, and the range mount kit that ships with it sits above an Atosa 36″ range to save space and speed up the line.
Key features
- Two 21,500 BTU/h ceramic infrared burners – 43,000 BTU/h in total, with high-efficiency infrared heat for fast browning.
- Dual valve controls – independent left and right-side operation, so you only fire the side you need.
- Standby pilots – a small flame stays ready to light the burners.
- Removable broiler rack and crumb catcher – pull the rack to clean it and empty the catch tray between services.
- Range mount kit included – ships with the cheesemelter; it is compatible only with an Atosa 36″ range.
- Stainless steel exterior and interior – tough and wipeable in a busy hot line.
- Optional wall mount kit – part # 21208001048 gives you a mounting alternative.
How the ATCM-36 fits your kitchen
The ATCM-36 is 36″ wide, 18″ deep and 17-1/3″ high, and weighs 95 lb. It connects to natural gas (regulator set at 5″ w.c.) or propane (10″ w.c.). Atosa’s manual says to install it beneath a compatible cooking fume exhaust hood, follow local ventilation codes, and place it on a level, non-combustible surface in an area kept free of combustibles. Leave access at the front and sides so panels can be removed for service, and have a licensed technician connect the gas.
Mounting options and accessories
- Range mount kit – included with the ATCM-36, for use with an Atosa 36″ range only.
- Wall mount kit – optional, part # 21208001048, for wall installation.
Why buy from Babak Food Equipment?
- Authorized Atosa dealer – sales, service and installation options, with warranty support coordinated with Atosa.
- 20+ years in business and a 4.9★ Google rating from 380+ reviews.
- Expert advice – our team helps you compare models and check power, gas and ventilation requirements.
- Delivery and installation options across BC – details and costs are discussed when you order.
FAQ
What gas and ventilation does the Atosa ATCM-36 need?
It runs on natural gas (5″ w.c. regulator) or propane (10″ w.c.), with a 3/4″ intake tube thread. Install it under a compatible exhaust hood meeting local codes, on a level non-combustible surface, away from combustibles.
How do I clean the ATCM-36?
Let it cool completely and turn off all valves. Wipe the body and control panel with a soft cloth and mild detergent daily, and empty and clean the catch tray at each use. Never hose down or pressure wash it, and avoid abrasives.
Where can I find the ATCM-36 spec sheet?
The official Atosa spec sheet, manual and parts breakdown for the ATCM-36 are in the download section below, with BTU ratings, gas pressures, dimensions and the wall mount kit part number.
Can I mount the ATCM-36 on any range?
The included range mount kit works only with an Atosa 36″ range. If you plan to mount it another way, Atosa lists an optional wall mount kit, part # 21208001048. Our team can help you plan the setup.
Please request a quote to confirm availability before you buy. Pricing, availability, warranty terms, delivery and installation are all confirmed at the time of purchase.
