Giles EOF-20/FFLT/24/24 Banked Electric Fryer with Dump Station – 20″ + Two 24″ Vats
Best Price Guarantee in Canada
REQUEST A QUOTE
Need Help :
Specs
| Weight | 1310 lbs |
|---|---|
| Brand | Giles |
| Model | EOF-20/FFLT/24/24 |
| Power Type | Electric |
| Capacity per Fry Pot | 115 lb. / 170 lb. |
| Number of Fry Pots | 3 |
| Voltage | 208/480 V |
| Phase | 3 Phase |
| Hertz | 60 Hertz |
| Control Type | Digital |
| Installation Type | Floor Model |
| Construction | Stainless Steel |
| Width | 97.6 Inches |
| Maximum Temperature | 350°F |
| Depth | 41.4 Inches |
| Height | 46.1 Inches |
| Power per Vat | 20″ vat 24 kW · 24″ vat 30 kW |
| Amps – 20" Vat | 76 A @ 208 V · 33 A @ 480 V |
| Amps – 24" Vat | 100 A @ 208 V · 43 A @ 480 V |
| Dump Station | Built-in (FFLT) |
| Filtration | Built-in central, 1/2 HP pump |
| Basket Lift | Standard on 20″ vat, optional on 24″ vats |
| Programmable Presets | 50 |
| Load capacity (reference) | 20″ vat 27–30 lb · 24″ vat 36–42 lb 8-way cut chicken |
Description
Giles EOF-20/FFLT/24/24 – Banked Electric Open Fryer with Built-In Dump Station
The Giles EOF-20/FFLT/24/24 is an ultra-high-volume banked fryer with one 20″ vat, a built-in dump station and two 24″ vats. Designed for operations where cooking large quantities of fried food quickly is the name of the game, it pairs fast recovery with a central on-board filtration system that serves every vat.
Key features
- 20″ × 20″ vat (115 lb oil, 24 kW) plus two 20″ × 24″ (170 lb oil, 30 kW each)
- Built-in dump station – a drain tube returns oil run-off to the on-board filtration collection pan
- Rapid recovery – oil quickly returns to cooking temperature after loading, even frozen product, so you turn more loads per shift
- Computer controllers with programmable cook timers, 50 menu presets, COOL mode, Force-Filter, Boil-Out, password control and multi-language display
- Automatic basket lift standard on the 20″ vat (optional on the 24″ vats)
- Central on-board oil filtration with 1/2 HP pump – a filter cycle in about 5 minutes; proper use can extend oil life by at least 50%
- Drain valve safety interlock, high-limit oil temperature protection and maximum element temperature shutdown
- 16–20 ga stainless steel, welded stainless frame, round Incoloy elements, 5″ swivel casters with front locking brakes
Options
- Automatic basket lifts on the 24″ vats
- KitchenTrac® WiFi remote monitoring
- Also available as the EOF-20/FFLT/24
Included
- 2 cook baskets (20″ vat) and 1 fry screen per vat
- 1 scoop-style basket
- FFLT drain grate
- Waste oil discharge hose
- Filter pan large crumb catcher
- Heat-resistant pot, drain and L-shape brushes, small FFLT drain brush and drain clean-out tool
- Stirring utensil and crumb shovel
Optional accessories
- Extra EOF-20 and EOF-24 baskets
- Scoop-style basket
- FFLT ribbed grate
- Filter paper, filter powder and boil-out
- Tool holder / splash guard
Ideal for
Extra-high-volume fried chicken, fish and QSR kitchens that want a complete frying and dumping line in one battery.
Why buy Giles from Babak Food Equipment?
- Authorized Giles dealer – sales, service and installation options through one team, with warranty support coordinated with Giles.
- Full-service team – delivery, installation and start-up can be arranged by our experienced technicians; details and costs are discussed when you order.
- Trusted by kitchens across Canada – 20+ years in business and a 4.9★ Google rating from 380+ reviews.
- Best offers – ask about complete high-volume fry lines – banked fryers, breading tables, landing tables and oil caddies.
FAQ
Is Babak Food Equipment an authorized Giles dealer?
Yes. We sell, install and service Giles fryers, ventless hoods and foodservice equipment, and coordinate warranty support with Giles. Warranty terms are confirmed at the time of purchase.
What is the FFLT section?
FFLT is the built-in dump station between the fryers. A drain tube returns oil run-off to the on-board filtration system, so less oil is wasted.
What electrical service does the EOF-20/FFLT/24/24 need?
Each fryer unit needs its own power supply – 208 V or 480 V, 60 Hz, three phase. The 20″ vat is 24 kW and each 24″ vat is 30 kW. Service cords are not included.
Is there a version without the dump station?
Yes. If floor or hood space is tight, the EOF-20/24/24 space-saver version has no dump station.
Please request a quote to confirm availability before you buy. Pricing, availability, warranty terms, delivery and installation are all confirmed at the time of purchase.
Get the best price on Giles: click Request a Quote or call our team at (604) 566-9747.
